Clutch Kit pDrive Ski-doo/Lynx 850 2017-

The market’s best variator kit for Ski-Doo/Lynx 850 Specially developed by BilletX for BRP 850 machines equipped with MAPTUN Stage 1 & 2 BilletX Variator Kit “MADE IN SWEDEN” The variator kit handles power from 120–220 HK on all machines with a pDrive variator. Fits: Ski-Doo / LYNX with ROTAX 850, 600R, 600RR 2017– - BRP 850 Gen 4 & Gen 5 variator kit - BilletX pDrive adjustable weights (3 pcs.) - Magnets (24 pcs.) weighing 1.5 g each - Stainless steel weight washers for the pivot bolt, 1.5 g each - BilletX QRS Helix 44/40 - Primary spring 200–330 & secondary spring 204–356 Compared to the stock setup, the BilletX variator kit provides quicker throttle response, excellent backshift, and more acceleration. + You can easily adjust your variator to match your tuning level from 160 to 250 Hk. Description: Setup Weights: 850 164 hk = 89 g: (Hole 1 = Closest to the weight pin) 1: 1 2: 2 Pivot bolt (38 mm original bolt) is weighted with 2 included M8 washers (8.4 x 15.6) MAPTUN Setup Step 1: 850 170 hk = 89 g: (Hole 1 = Closest to the weight pin) 1: 0 2: 3 Pivot bolt (38 mm original bolt) is weighted with 2 included M8 washers (8.4 x 15.6) MAPTUN Setup Step 2: 850 179 hk = 90.5 g: (Hole 1 = Closest to the weight pin) 1: 1 2: 3 The pivot bolt (38 mm original bolt) is weighted with 2 of the included M8 washers (8.4 x 15.6) We recommend purchasing a small scale with 0.01-gram resolution when adjusting the weight yourself. Good to know. - More weight at the toe will increase the swing speed and result in a higher gear ratio and higher top speed. - More weight in the heel will lower the strike speed and provide more acceleration and mid-range power. - More weight in general lowers the top speed, while less weight raises the top speed.
